Parameters
Model Name
TS1000 Plus Series
Visual Indicator
Steady green = Normal use
Steady red = Barrier closedAudio Indicator
Internal buzzer
Lane Type
Single lane
Lane Width (mm)
550
Barrier Movement Type
Rotating
Lid Material
SUS304 stainless steel
Lid Options Authentication Methods
Streamlined under mount options:Fingerprint / RFID
Chassis Material
SUS304 stainless steel (T=1.2mm)
Chassis Color
Silver-gray
Barrier Material
SUS304 stainless steel
Motherboard Function
Barrier open duration, access mode
Motherboard Communication
Fire alarm port (relay)*1, RS485 port *1
Controller
C3-200 Pro Plus & InBio260 Pro Plus (Recommended)
Other controller depends on dimensions fitting in (Optional)Credential Options
Under mount RFID reader: ProID Series, KR Series (Supported model)
Under mount fingerprint reader: FR1200 / FR1500SFlow Rate
RFID: 25 passengers per minute
Fingerprint: 20 passengers per minuteFootprint (mm*mm)
100*420
Barrier Width
500mm
Accessibility
Wireless remote control, wired remote control, QR reader
Power Supply
110V / 220V AC@50 to 60 Hz, DC 12V
Power Rating
10VA (standby)
40VA (operation)Fire Signal
Input for voltage free contact
Noise Level
Less than 65dB
MTTR
Less than 60 minutes
MCBF
2 million
Weight (kg)
Gross weight (25kg)
Net weight (20kg)Dimension (L*W*H)
780*750*1000mm
Operating Temperature
-20°C to 70°C
Operating Humidity
0% to 85% RH (Non-condensing)
Certifications
CE, FCC, UKCA, ISO 9001
Ingress Protection Rating
IPX4
Supported Software
ZKBio CVAccess / ZKBio CVSecurity
(depends on equipped access controller)Safety Features
Voltage free contact input for fire alarm fail state automatic drop arm during power off
Security Features
Anti-tailgating
Product Delivery
press-assembled
Application Environment
Indoor / outdoor (if sheltered)
Site Preparation
Flat & level finished floor (base plate in options for unfinished floor)
Dimensions with Packing ( L*W*H )
380 * 520 * 1100mm
Security Level
Medium
Emergency Mode
Support (drop arm)
Packing Material
Cartoon (Standard), wooden (Optional)
