Parameters
Model Name
Saturn-T1000 Series
Audio Indicator
Buzzer
Visual Indicator
LED Indicator
Blue: Standby
Green: Access Granted
Red: Alarm / ErrorDisplay
N/A
Lane Type
Single lane
(Support bi-directional entry / exit lane)Barrier Movement Type
Rotating (Tripod)
Lane Width
550 mm
Motor
Not specified
Movement Speed
N/A
Movement Accuracy
N/A
Clutch
N/A
Lid Material
Polycarbonate + 2.5D tempered glass
Lid Options Authentication Methods
RFID / Facial Recognition / QR code (Dynamic / Static)
Chassis Material
Cold-rolled SPCC Steel (GB700) (with powder coating finishing)
Chassis Color
Pearl White (PWH)
Tripod Rod Materia
SUS304 Stainless Steel
IR Sensors
N/A
Motherboard Function
System mode configuration. Access mode configuration
Motherboard Communication
Fire alarm Port (Relay)*1, RS485 port *1
Controller
Access controller Options: C3, InBio series or third-party controller subject to turnstile chassis space
Credential Options
Post mount Facial Recognition Device: G4 Pro
Under mount QR code Reader: QR500
Under mount RFID Reader: ProID10Flow Rate
Face: 15 Passengers per minute
RFID: 25 Passengers per minute
QR code: 25 Passengers per minuteAccessibility
N/A
Power Supply
AC 110V~220V, 50/60Hz, DC 12V
Power Rating
Operating: 40W, Standby: 10W
Fire Signal
Input for voltage-free contact
Noise Level
< 65 dB
MTTR
N/A
Weight
25 kg
Dimensions ( L*W*H )
1200 * 734 * 1020 mm
Dimensions of Product Parts with Packaging ( L*W*H )
1300 * 305 *1106 mm
Certifications
CE, FCC
Operating Temperature
-20°C to 70°C
Ingress Protection Rating
Self-laboratory test: equivalent to IPX4
Operating Humidity
20% to 80% RH (Non-condensing)
Supported Software
ZKBio CVAccess / ZKBio CVSecurity (Compatible with software only when connected to the control panel)
Safety Features
Auto drop arm during power failure and re alarm emergency
Security Features
Anti-tailgating
Product Delivery
Pre-assembled
Application Environment
Indoor / Outdoor (If sheltered)
Site Preparation
Flat and level finished floor (optional base plate for unfinished floors)
Security Level
Middle
Emergency Mode
Drop arm function engages during power outage or fire alarm events
Packing Material
Carton box
